VHOVMV-K 300/500V Flexible Armoured Instrumentation Cable with Copper Conductor and PVC Insulation

Name: VHOVMVK 300500V Flexible Armoured Instrumentation Cable with Copper Conductor and PVC Insulation
Brand: Minfeng
Price: 0.1 USD

Wholesale VHOVMV-K 300/500V Flexible Armoured Instrumentation Cable with Copper Conductor and PVC Insulation from china suppliers

Place of Origin : Hebei, China

Conductor Material : Copper

Rated Voltage : 300/500V

Model Number : VHOVMV-K

Price : 0.1-5

Payment Terms : L/C,T/T

Trademark : Minfeng Cable Group

Insulation material : PVC

Certification : ISO,CE,IEC,TUV,KEMA

Brand Name : Minfeng

Sheathmaterial : PVC

Supply Ability : 100KM/Week

Temperature Rating : -40 °C to +70 °C

Outer Sheath Color : Black or as per required

MOQ : 100

Delivery Time : 10 Days

Contact Now

VHOVMV-K 300/500V Flexible Armoured Instrumentation Cable Copper Conductor PVC Insulation

Product Overview

Flexible armoured instrumentation cable with individual and overall foil shielding, PVC insulation and sheath. Designed for signal transmission between equipment in industrial installations.

Rated Voltage	300/500V
Conductor Size	1.5mm², 2.5mm²
Conductor Material	Copper
Insulation Material	PVC
Working Temperature	-40°C to +70°C
Application	Industrial
Standard	Class 5 to IEC 60228

Cable Design & Construction

Single Shield: Aluminium/polyester tape applied on each pair with 100% coverage + tinned copper drain wire
Overall Cable Shield: Aluminium/polyester tape with 100% coverage + tinned copper drain wire
Armouring: Galvanized steel wire core
Conductor: Bare copper wires, flexible, Class 5 to IEC 60228
Insulation: PVC
Wiring: Two conductors form twisted pairs with optimum pitch to minimize external interference
Identification: Numbered black and blue
Sheath: Special PVC, Black color

Technical Characteristics

Service temperature in fixed and protected installation: -40°C to +70°C
Service voltage: 300/500V
Max. conductor temperature: +70°C
Max. temperature in short circuit (max. 5 sec): +160°C
Test voltage: 2,000V AC
Capacity: ≤85 nF/km (can be increased by 20% from 4 pairs)
Minimum bend radius in fixed installation: 10 x outer diameter

Performance Properties

Water resistance: AD5 Jets (water jets from any direction)
Impact resistance: AG4 Very strong (reinforced for severe industrial use)
Oil resistance: ICEA S-73-532
Resistance to hydrocarbons: ICEA S-73-532 (4h, 70°C)
UV resistance: Good (possible sheath discolouration over long time)
RoHS compliant: Free of harmful substances according to RoHS II

Fire Resistant Properties

Euroclase: CPREca
Fire requirements: EN 50575
Flame retardant: EN 60332-1-2, IEC 60332-1-2, VDE 0482-332-1-2, NFC 32070 C2

Product Images

VHOVMV-K 300/500V Flexible Armoured Instrumentation Cable with Copper Conductor and PVC Insulation

VHOVMV-K 300/500V Flexible Armoured Instrumentation Cable with Copper Conductor and PVC Insulation Images
